TWT UTP cable, 4 pairs, category 6, PVC, grey, 305 m
TWT UTP cable, 4 pairs, category 6, PVC, grey, 305 m
TWT-6UTP-GY
The cable comprises 4 pairs of stranded copper conductors.
Conductor gauge is 23AWG.
Each conductor is covered with HDPE (high density polyethylene) insulation.
Two conductors are twisted with specially selected step in a single twisted pair.
Pairs in the cable are parted with a separator which increase cross attenuation between the pairs.
Four pairs and the separator are coated with single PVC jacket.
There is a ripcord under the jacket to ease termination process.
| Specification | Value |
| Jacket Color | Grey |
| Jacket Material | PVC |
| Conductor Gauge, single | 23 AWG |
| Conductor Type | Solid |
| Cable Diameter | 6.4 mm |
| Operating Temperature | -20 ºC to 75 ºC |
| Cable Length per Box | 305 m |
| Nominal velocity propagation (NVP) | 69% |
| Regulatory Certifications | UL, ETL and 3P Verified |
| Regulatory Compliance | TIA/EIA568-D.2-1 Category 6, ISO/IEC 11801-1:2017, EN 50288-6-1:2013 |
