TWT UTP cable, 100 pairs, category 5, PVC, 305 meters on a reel
Cable comprises 100 pairs of solid copper conductors.
It is compliance with category 5.
Each conductor is covered with HDPE (high density polyethylene) insulation.
Two conductors are twisted with specially selected step in a single twisted pair. Each group of 25 twisted pairs are gathered around a core element and fixed with a wrapper tape with different color per group. The four bundles are covered with a single PVC jacket.
There is a ripcord under the cable jacket for termination process convenience.
The cable is delivered on reels by 305 meters length. Other construction lengths are available by order.
| Specification | Value |
| Jacket Color | Blue |
| Jacket Material | PVC |
| Insulation Material | HDPE (high density polyethylene) |
| Conductor Type | Solid |
| Conductor Gauge | 24 AWG |
| Nominal Velocity Propagation (NVP) | 66% |
| Cable Diameter | 27.5 mm |
| Cable Length per Reel | 305 m |
| Operating Temperature | -20 ºC to 75 ºC |
| Regulatory Certifications | UL VERIFIED |
| Regulatory Compliance | TIA/EIA 568.2-D cat. 5; ISO/IEC 11801 |
| Color Coding | |||
| Pair | Color | Pair | Color |
| 1 | white - blue | 13 | black - green |
| 2 | white - orange | 14 | black - brown |
| 3 | white - green | 15 | black - grey |
| 4 | white - brown | 16 | orange - blue |
| 5 | white - grey | 17 | orange - orange |
| 6 | red - blue | 18 | orange - green |
| 7 | red - orange | 19 | orange - brown |
| 8 | red - green | 20 | orange - grey |
| 9 | red - brown | 21 | purple - blue |
| 10 | red - grey | 22 | purple - orange |
| 11 | black - blue | 23 | purple - green |
| 12 | black - orange | 24 | purple - brown |
|
|
| 25 | purple - grey |
