TWT UTP, 50 pairs, category 5e, PVC, 305 meters on a reel
Cable comprises 10 pairs of solid copper conductors.
It is compliance with category 5e.
Each conductor is covered with HDPE (high density polyethylene) insulation.
Two conductors are twisted with specially selected step in a single twisted pair. Twisted pairs are gathered around a strength core element, wrapped with polyethylene tape, and covered with a single PVC jacket.
There is a ripcord under the cable jacket for termination process convenience.
The cable is delivered on reels by 305 meters length. Other construction lengths are available by order.
| Specification | Value |
| Jacket Color | Blue |
| Jacket Material | PVC |
| Insulation Material | HDPE (high density polyethylene) |
| Conductor Type | Solid |
| Conductor Gauge | 24 AWG |
| Nominal Velocity Propagation (NVP) | 66% |
| Cable Diameter | 15.8 mm |
| Cable Length per Reel | 305 m |
| Operating Temperature | -20 ºC to 75 ºC |
| Regulatory Certifications | UL VERIFIED |
| Regulatory Compliance | TIA/EIA 568.2-D cat. 5; ISO/IEC 11801 |
| Color Coding | |||
| Pair | Color | Pair | Color |
| 1 | white - blue | 26 | white/brown - blue |
| 2 | white - orange | 27 | white/brown - orange |
| 3 | white - green | 28 | white/brown - green |
| 4 | white - brown | 29 | white/brown - brown |
| 5 | white - grey | 30 | white/brown - grey |
| 6 | red - blue | 31 | red/grey - blue |
| 7 | red - orange | 32 | red/grey - orange |
| 8 | red - green | 33 | red/grey - green |
| 9 | red - brown | 34 | red/grey - brown |
| 10 | red - grey | 35 | red/grey - grey |
| 11 | black - blue | 36 | black/orange - blue |
| 12 | black - orange | 37 | black/orange - orange |
| 13 | black - green | 38 | black/orange - green |
| 14 | black - brown | 39 | black/orange - brown |
| 15 | black - grey | 40 | black/orange - grey |
| 16 | yellow - blue | 41 | yellow/blue - blue |
| 17 | yellow – orange | 42 | yellow/blue - orange |
| 18 | yellow - green | 43 | yellow/blue - green |
| 19 | yellow - brown | 44 | yellow/blue - brown |
| 20 | yellow - grey | 45 | yellow/blue - grey |
| 21 | purple - blue | 46 | purple/green - blue |
| 22 | purple - orange | 47 | purple/green - orange |
| 23 | purple - green | 48 | purple/green - green |
| 24 | purple - brown | 49 | purple/green - brown |
| 25 | purple - grey | 50 | purple/green - grey |
| Note the color coding for 26-50th pairs! | |||
