TWT UTP cable, for patch-cords, 2 pair, cat. 5e, PVC, 305 meters
TWT UTP cable, for patch-cords, 2 pair, cat. 5e, PVC, 305 meters
TWT-5EUTP2PT-xx
The cable consists of 2 pairs of stranded copper conductors.
The cable consists of 2 pairs of stranded copper conductors.Conductor diameter is 24AWG.
Each conductor is insulated with HDPE (high density polyethylene).
Two conductors twisted with a specially selected step and forming one twisted pair.
Two twisted pairs are enclosed in a common PVC jacket.
| Conductor | Material | Copper |
| Type | 7 wires / 0.18 ± 0.01 mm | |
| Insulation | Material | HDPE |
| Thickness | 0.19 mm | |
| Diameter | 0.92 ± 0.05 mm | |
| Jacket | Material | PVC |
| Thickness | 0.55 mm | |
| Diameter | ||
| Wave impedance | max. 116 Ohm/km at 20℃ | |
