TWT UTP cable, for patch-cords, 1 pair, cat. 5e, PVC, 305 meters, grey
TWT UTP cable, for patch-cords, 1 pair, cat. 5e, PVC, 305 meters, grey
TWT-5EUTP1PT-GY
The cable consists of one pair of stranded copper conductors.
Conductor diameter is 24AWG.
Each conductor is insulated with HDPE (high density polyethylene).
Two conductors twisted with a specially selected step and forming one twisted pair are enclosed in a common PVC jacket.
| Conductor | Material | Copper |
| Type | 7 wire / 0.18 ± 0.01 mm | |
| Insulation | Material |
HDPE |
| Thickness | 0.19 mm | |
| Diameter | 0.92 ± 0.05 мм | |
| Jacket | Material | PVC |
| Thickness | 0.50 mm | |
| Diameter | 2.8 ± 0.20 mm | |
| Wave impedance |
max. 116 Ohm/km at 20℃ | |
| Insulation Resistance |
min. 10 MOhm/m at 20℃ | |
