TWT UTP cable, single pair, cat. 5E, PVC, grey, 305 m
TWT UTP cable, single pair, cat. 5E, PVC, grey, 305 m
TWT-5EUTP1-GY
Single pair cables are budget solution for voice, fair alarm, and security cabling. Also, they can be used as cross wires.
The cable comprises two solid copper 24 AWG conductors. Each conductor is insulated with HDPE (high density polyethylene). Those two conductors are twisted with specially selected step in a single twisted pair and covered with PVC jacket.
| Specification | Value |
| Jacket Color | Grey |
| Jacket Material | PVC (polyvinyl chloride) |
| Insulation Material | HDPE (high density polyethylene) |
| Conductor Gauge, single | 24 AWG |
| Conductor Type | Solid |
| Cable Diameter | 3 mm |
| Operating Temperature | -20 ºC to +75 ºC |
| Cable Length per Box | 305 m |
| Regulatory Certifications | ETL VERIFIED, UL, CSA |
| Regulatory Compliance | TIA/EIA 568-D.2 cat. 5e |
