TWT UTP cable, 4 pairs, category 5e, for patch-cords (stranded), PVC, 305 meters, grey
TWT UTP cable, 4 pairs, category 5e, for patch-cords (stranded), PVC, 305 meters, grey
TWT-5EUTP-PT-GY
The cable comprises 4 pairs of stranded copper conductors. Conductor gauge is 24AWG.
Each conductor is covered with HDPE (high density polyethylene) insulation.
Two conductors are twisted with specially selected step in a single twisted pair.
The cable comprises four twisted pairs of solid copper conductors under a single PVC jacket.
| Specification | Value |
| Jacket Color | Grey |
| Jacket Material | PVC |
| Insulation Material | HDPE (high density polyethylene) |
| Conductor Type | Stranded (7 wires / 0.18 ± 0.01 mm) |
| Conductor Gauge | 24 AWG |
| Cable Diameter | 5.1 ±0.2 mm |
| Nominal velocity propagation (NVP) | 66% at 100 MHz |
| Cable Length per Box | 305 m |
| Operating Temperature | -20 ºC to +75 ºC |
| Regulatory Certifications | ETL VERIFIED |
| Regulatory Compliance | TIA/EIA 568-D.2 cat. 5E, ISO/IEC 11801-1:2017, EN 50173 |
