TWT UTP cable, 4 pairs, category 5е, outdoor, 305 m
TWT UTP cable, 4 pairs, category 5е, outdoor, 305 m
TWT-5EUTP-OUT
The cable is suitable for outdoor installation. Polyethylene jacket reliable protects cable from harsh environment, does not degrade under Solar radiation, and allows operational temperatures from 40oС to +75 oС.
Four pairs UTP cable has a following design:
Conductor is a solid 24 AWG wire with HDPE (high density polyethylene) insulation.
Two conductors comprise a single twisted pair. The cable consists of four pairs, each pair twisted with different but specially selected step.
The cable jacket has per meter length marks.
| Specification | Value |
| Jacket Color | Black |
| Jacket Material | PE (polyethylene) |
| Insulation Material | HDPE (high density polyethylene) |
| Conductor Gauge, single | 24 AWG |
| Conductor Type | Solid |
| Cable Diameter | 4.8 mm |
| Operating Temperature | -20 ºC to +75 ºC |
| Cable Length per Box | 305 m |
| Nominal velocity propagation (NVP) | 66% |
| Regulatory Certifications | UL, ETL VERIFIED |
| Regulatory Compliance | TIA/EIA 568-D.2 cat. 5E, ISO/IEC 11801-1:2017; EN 50173 |
The cable has better transmission characteristics then defined in standards for 1-100 MHz frequency band.
