TWT FTP outdoor, 25 pairs, category 5e, outdoor, 305 meters on a reel
The cable comprises 25 pairs of solid copper conductors. It is compliance with category 5e.
Each conductor is covered with HDPE (high density polyethylene) insulation. Two conductors are twisted with specially selected step in a single twisted pair.
The twisted pairs are gathered around a core element, wrapped in polyethylene tape and laminated foil, and covered with a single PE (polyethylene) jacket.
There is a ripcord under the cable jacket for termination process convenience.
| Specification | Value |
| Jacket Color | Black |
| Jacket Material | PE (polyethylene) |
| Insulation Material | HDPE (high density polyethylene) |
| Conductor Type | Solid |
| Conductor Gauge | 24 AWG |
| Nominal Velocity Propagation (NVP) | 66% |
| Cable Diameter | 14.0 mm |
| Cable Length per Reel | 305 m |
| Operating Temperature | -20 ºC to 75 ºC |
| Regulatory Certifications | UL, ETL |
| Regulatory Compliance | TIA/EIA 568.2-D cat. 5; ISO/IEC 11801; EN50173 |
| Color Coding | |||
| Pair | Color | Pair | Color |
| 1 | white - blue | 13 | black - green |
| 2 | white - orange | 14 | black - brown |
| 3 | white - green | 15 | black - grey |
| 4 | white - brown | 16 | orange - blue |
| 5 | white - grey | 17 | orange - orange |
| 6 | red - blue | 18 | orange - green |
| 7 | red - orange | 19 | orange - brown |
| 8 | red - green | 20 | orange - grey |
| 9 | red - brown | 21 | purple - blue |
| 10 | red - grey | 22 | purple - orange |
| 11 | black - blue | 23 | purple - green |
| 12 | black - orange | 24 | purple - brown |
|
|
| 25 | purple - grey |
