TWT FTP cable, 10 pairs, category 5e, PVC, 305 meters on a reel
The cable comprises 10 pairs of solid copper conductors. It is compliance with category 5e.
Each conductor is covered with HDPE (high density polyethylene) insulation. Two conductors are twisted with specially selected step in a single twisted pair.
The twisted pairs are gathered around a filler rope, wrapped in laminated foil and covered with a single PVC jacket.
There is a ripcord under the cable jacket for termination process convenience and a drain wire for continuous grounding under the foil layer.
The cable is delivered on reels by 305 meters length. Other construction lengths are available by order.
| Specification | Value |
| Jacket Color | Blue |
| Jacket Material | PVC (polyvinyl chloride) |
| Insulation Material | HDPE (high density polyethylene) |
| Conductor Type | Solid |
| Conductor Gauge | 24 AWG |
| Nominal Velocity Propagation (NVP) | 66% |
| Cable Diameter | 8.3 mm |
| Cable Length per Reel | 305 m |
| Operating Temperature | -20 ºC to 75 ºC |
| Regulatory Certifications | UL |
| Regulatory Compliance | TIA/EIA 568.2-D cat. 5; ISO/IEC 11801; EN50173 |
| Color Coding | |||
| Pair | Color | Pair | Color |
| 1 | white - blue | 6 | red - blue |
| 2 | white - orange | 7 | red - orange |
| 3 | white - green | 8 | red - green |
| 4 | white - brown | 9 | red - brown |
| 5 | white - grey | 10 | red - grey |
