FTP cable, 4 pairs, XS series, category 5е, outdoor, PE
Shielded category 5e cable is designed for digital and analog signals transmission on frequencies below 100 MHz.
Polyethylene jacket has high rigidity against low temperature, high humidity, and solar radiation what makes the cable suitable for outdoor installations.
The cable comprises four twisted pairs of solid copper conductors with overall foil shield under a single jacket.
| Specification | Value |
| Jacket Color | Black |
| Jacket Material | PE (polyethylene) |
| Insulation Material | HDPE (high density polyethylene) |
| Conductor Type | Solid |
| Conductor Gauge | 24 AWG |
| Nominal Velocity Propagation (NVP) | 66% |
| Cable Diameter | 6.2 mm |
| Cable Length per Reel | 305 m |
| Operating Temperature | -20 ºC to 75 ºC |
| Color Coding | |||
| Pair | Color | Pair | Color |
| 1 | blue/white-blue | 3 | orange/white-orange |
| 2 | green/white-green | 4 | brown/white-brown |
