TWT UTP cables, 100 pairs, category 3, PVC, 305 meters on a reel
Cable comprises 100 pairs of solid copper conductors.
Each conductor is covered with HDPE (high density polyethylene) insulation.
Two conductors are twisted with specially selected step in a single twisted pair. Twisted pairs are grouped in bundles by 25 pairs and fixed with a polyethylene tape and a technological yarn. The bundles are enclosed in a single PVC jacket.
There is a ripcord under the cable jacket for termination process convenience.
The cable is delivered on reels by 305 meters length. Other construction lengths are available by order.
| Specification | Value |
| Jacket Color | Grey |
| Jacket Material | PVC |
| Insulation Material | HDPE (high density polyethylene) |
| Conductor Type | Solid |
| Conductor Gauge | 24 AWG |
| Nominal Velocity Propagation (NVP) | 66% |
| Cable Diameter | 20.0 mm |
| Cable Length per Reel | 305 m |
| Operating Temperature | -20 ºC to 75 ºC |
| Regulatory Certifications | UL VERIFIED |
| Regulatory Compliance | TIA/EIA 568.2-D cat. 3; ISO/IEC 11801 |
| Color Coding | |||
| Pair | Color | Pair | Color |
| 1 | white - blue | 13 | black - green |
| 2 | white - orange | 14 | black - brown |
| 3 | white - green | 15 | black - grey |
| 4 | white - brown | 16 | orange - blue |
| 5 | white - grey | 17 | orange - orange |
| 6 | red - blue | 18 | orange - green |
| 7 | red - orange | 19 | orange - brown |
| 8 | red - green | 20 | orange - grey |
| 9 | red - brown | 21 | purple - blue |
| 10 | red - grey | 22 | purple - orange |
| 11 | black - blue | 23 | purple - green |
| 12 | black - orange | 24 | purple - brown |
|
|
| 25 | purple - grey |
