Indoor Cable with нг(А)-HF Jacket and micro-modules
Application:
Used as a distribution cable for cabling inside buildings, in cable trays, in cable ducts, pipes and tunnels.
Design:
The cable contains a bundle of micro-modules with optical fibers which is covered with a layer of strength aramid yarn. The cable jacket is made of a flame retardant, halogen-free, low-smoke polymer composition.
The cable jacket is manufactured:
- yellow color for OS2 single mode fiber
- orange color for OM1, OM2 multimode fiber
- aqua color for OM3 multimode fiber
- pink color for OM4 multimode fiber
The maximum possible count of optical fibers in the cable is 288.
Color identification of optical fibers and micromodules:
| Fiber color | Micro-module color | ||||
| № | Fibers 1-12 | № | Modules 1-12 | № | Modules 13-24 |
| 1 | Blue | 1 | Blue | 13 | Blue + 1 mark |
| 2 | Orange | 2 | Orange | 14 | Orange + 1 mark |
| 3 | Green | 3 | Green | 15 | Green + 1 mark |
| 4 | Brown | 4 | Brown | 16 | Brown + 1 mark |
| 5 | Grey | 5 | Grey | 17 | Grey + 1 mark |
| 6 | White | 6 | White | 18 | White + 1 mark |
| 7 | Red | 7 | Red | 19 | Red + 1 mark |
| 8 | Black | 8 | Black | 20 | Black + 1 mark |
| 9 | Yellow | 9 | Yellow | 21 | Yellow + 1 mark |
| 10 | Violet | 10 | Violet | 22 | Violet + 1 mark |
| 11 | Pink | 11 | Pink | 23 | Pink + 1 mark |
| 12 | Turquoise | 12 | Turquoise | 24 | Turquoise + 1 mark |
Weight and Dimensions:
| Fiber count | Cable diameter, mm | Cable weight, kg/km |
| 4 (1х4) | 5,0 | 26,8 |
| 8 (2х4) | 5,5 | 30,6 |
| 8 (4х2) | 5,9 | 34,7 |
| 12 (2х6) | 5,8 | 33,4 |
| 12 (6х2) | 6,4 | 39,5 |
| 16 (4х4) | 6,2 | 37,2 |
| 24 (4х6) | 6,7 | 41,8 |
| 24 (6х4) | 6,7 | 42,9 |
| 24 (12х2) | 7,6 | 52,0 |
| 36 (6х6) | 7,4 | 49,1 |
| 48 (6х8) | 7,5 | 51,2 |
| 48 (8х6) | 8,0 | 55,7 |
| 48 (12х4) | 8,1 | 57,8 |
| 64 (8х8) | 8,2 | 58,4 |
| 64 (16х4) | 8,8 | 66,6 |
| 72 (6х12) | 8,0 | 56,1 |
| 72 (12х6) | 9,0 | 67,8 |
| 96 (8х12) | 8,8 | 64,4 |
| 96 (12х8) | 9,3 | 71,5 |
| 96 (16х6) | 9,9 | 78,8 |
| 144 (12х12) | 10,0 | 79,4 |
| 144 (24х6) | 11,5 | 99,1 |
| 192 (16х12) | 11,1 | 93,3 |
| 192 (24х8) | 11,8 | 105,6 |
| 288 (24х12) | 12,8 | 118,8 |
Operating conditions:
| Operating Temperature | -10°С…+50°С |
| Installation Temperature | -10°С…+50°С |
| Storage Temperature | -50°С…+50°С |
| Minimum Bend Radius | At least 10 cable diameters |
| Lifetime | 25 years |
Cable physical characteristics:
Optical cable is resistant to the following impacts
| Impact type | Nominal value | Criteria for evaluation |
| Installation pulling tension (IEC 794-1-93 Е1 test procedure) | 800 N | Δα* ≤ 0,05 dB no damage |
| Long-term pulling tension (IEC 794-1-93 Е1 test procedure) | 400 N | |
| Crushing strength (IEC 794-1-9З Е3 test procedure) | 100 N/cm | |
| Dynamic Bending Stresses (IEC 794-1-93 Е6 test procedure) | 20 cycles at an angle ±90° | |
| Axial twisting stresses (IEC 794-1-93 Е7 test procedure) | - 10 cycles | |
| - at an angle of ± 360 ° at a length of 4 m | ||
| Impact (IEC 794-1-93 Е4 test procedure) | Impact energy is 3 J | |
| Climatic impact (IEC 794-1-93 F1 test procedure) | - temperature range from minus 10 to 50 °С | Δα ≤ 0,05 dB/km |
| - 2 cycles | ||
| - cycle duration ≥ 16 hours |
* - increase in attenuation of an optical fiber in a cable at specific wavelengths.
| Product code | Description |
| LAN-OFC-DIMxx-yy-HF | Indoor FO cable, Distribution, нг(А)-HF, xx (n x m) fibers, OS2 Ultra/OS2/OM1/OM2/OM3/OM4, yellow/orange/aqua/pink |
xx – fiber count
yy – fiber type (SU, S2, S5, S7, M1, M2, M3, M4)
n - micro-modules count
m – fibers count in micro-module
Applicable optical fibers:
| SU | Single-mode fiber with extended operating wavelength and reduced attenuation and low bending loss (ITU G.652D+G.657.A1 recommendation) |
| S2 | Single-mode fiber with an extended bandwidth of operating wavelengths (ITU-T G.652D recommendation) |
| S5 | Single-mode positive non-zero dispersion shifted fiber (ITU-T G.655 recommendation) |
| S7 | Single-mode with low bending loss (ITU-T G.657 recommendation) |
| M1 | Multi-mode with core to cladding ratio 62,5/125 μm (IEC 60793-2-10 A1b type recommendation) |
| M2 | Multi-mode with core to cladding ratio 50/125 μm (ITU-T G.651 recommendation and IEC 60793-2-10 type A1a.1 requirements) |
| M3 | Multi-mode with low bending loss and core to cladding ratio 50/125 μm (ITU-T G.651 recommendation and IEC 60793-2-10 A1a.2 type requirements) |
| M4 | Multi-mode with low bending loss and core to cladding ratio 50/125 μm (ITU-T G.651 recommendation and IEC 60793-2-10 A1a.3 type requirements) |
The cable is supplied on request. Check the availability and delivery time with the company's managers.
